Industry-Preferred Cryogenic Freezing Bags

Intended Use: The OriGen Biomedical® CryoStore bags are intended to freeze blood components.

Registration

FDA 510(k) Cleared. CE Marked.

OriGen Biomedical sells directly and works with a network of global distributors. For availability in your country, please contact us below.

  • Protect Your Cells

    Hermetically sealed spike ports provide a tamper-proof design. The EVA film used in every CryoStore bag is biologically safe for its use, and its durability has been proven through validation and customer success.

  • Traceability

    A permanent lot number* is heat welded into the tail of each bag. Each** bag has a donor tube with printed segments of approximately 100uL that match the printed number on the bag.

  • User Inspired Design

    Stock tubing sets may include luer-activated needle-free valves, sterile-weldable tubing, roller clamps, and/or luer connectors. The donor tube is placed in the corner of each bag for easier de-bubbling and sealing.

  • Closed System Processing

    OriGen provides products that enable the user to manipulate cellular products in a closed system, reducing the risk of contamination.

* Permanent lot number is not the same as the OriGen production lot number on the pouch or case. │ ** Except 1000 and 2000 size bags.

ML34.R07

Interested in the CryoStore Freezing Bag?

Contact us today to get a price quote or sample products.

Contact Us

Product Use

Product Code

Description

Tube Set Description

Case Qty



CS28V CryoStore 28 EVA Freezing Bag, 10-25ml, “V” Tubing Set Female luer with injection Y to two CS28 bags with pinch clamps 24

Special Order

CS50 CryoStore 50 EVA Freezing Bag, 10 – 30ml, “Standard” Tube Set Two female luers with caps 24
CS50M3 CryoStore 50 EVA Freezing Bag, 10 – 30ml, “M3” Tube Set One male luer with cap, two female luers with caps, a needle-free injection port and a pinch clamp 24

Special Order

CS50N CryoStore 50 EVA Freezing Bag, 10 – 30ml,  “N” Tube Set One male luer with cap, two female luers with caps, and a needle-free injection port 24
CS50NS CryoStore 50 EVA Freezing Bag, 10 – 30ml, “N” Tube Set, double aseptically packed One male luer with cap, two female luers with caps, and a needle-free injection port 12
CS50S CryoStore 50 EVA Freezing Bag, 10 – 30ml, “Standard” Tube Set, double aseptically packed Two female luers with caps 12
CS50V7 CryoStore multiple bag set, ten 50 EVA freezing bags, 10- 30 ml, and one 750 EVA freezing bag, 80-190ml, “V7” Tube Set Female luers with caps, “Y” connectors, pinch clamps, slide clamps, co-extruded EVA/PVC tubing and a 30 cm PVC tube 1

Special Order

CS250 CryoStore 250 EVA Freezing Bag, 30 – 70ml, “Standard” Tube Set Two female luers with caps 24
CS250N CryoStore 250 EVA Freezing Bag, 30 – 70ml,  “N” Tube Set One male luer with cap, two female luers with caps, and a needle-free injection port 24
CS250NS CryoStore 250 EVA Freezing Bag, 30 – 70ml,  “N” Tube Set, double aseptically packed One male luer with cap, two female luers with caps, and a needle-free injection port 12
CS250NSW CryoStore 250 EVA Freezing Bag, 30 – 70ml,  “N” Tube Set, double aseptically packed in OW One male luer with cap, two female luers with caps, and a needle-free injection port 12
CS250S CryoStore 250 EVA Freezing Bag, 30 – 70ml, “Standard” Tube Set, double aseptically packed, one bag Two female luers with caps 12

Special Order

CS500 CryoStore 500 EVA Freezing Bag, 55 – 100ml, “Standard” Tube Set Two female luers with caps 24
CS500i3 CryoStore 500 EVA Freezing Bag, 55 -100ml, custom length 7.5 inches, “Standard” Tubing Set Two female luers with roller clamps 24

Special Order

CS500N CryoStore 500 EVA Freezing Bag, 55 – 100ml,  “N” Tube Set One male luer with cap, two female luers with caps, and a needle-free injection port 24
CS500NS CryoStore 500 EVA Freezing Bag, 55 – 100ml,  “N” Tube Set, double aseptically packed One male luer with cap, two female luers with caps, and a needle-free injection port 12
CS500NSW CryoStore 500 EVA Freezing Bag, 55 – 100ml,  “N” Tube Set, double aseptically packed in OW One male luer with cap, two female luers with caps, and a needle-free injection port 12
CS500V2 Custom CryoStore 500 EVA 2-Bag set with spikes, 55-100ml, “V2” Tube Set, 2 sets per pouch One nylon spike with cover, one male luer with cap, a needle-free injection port and pinch clamps 12

Special Order

CS750 CryoStore 750 EVA Freezing Bag, 80 – 190ml, “Standard” Tube Set Two female luers with caps 24
CS750N CryoStore 750 EVA Freezing Bag, 80 – 190ml,  “N” Tube Set One male luer with cap, two female luers with caps, and a needle-free injection port 24
CS750NS CryoStore 750 EVA Freezing Bag, 80 – 190ml, “N” Tube Set, double aseptically packed One male luer with cap, two female luers with caps, and a needle-free injection port 12
CS750NSW CryoStore 750 EVA Freezing Bag, 80 – 190ml, “N” Tube Set, double aseptically packed in OW One male luer with cap, two female luers with caps, and a needle-free injection port 12
CS1000N CryoStore 1000 EVA Freezing Bag, 120 – 275ml,  “N” Tube Set One male luer with cap, two female luers with caps, and a needle-free injection port with roller clamps 24
CS2000N CryoStore 2000 EVA Freezing Bag, 180 – 450ml freezing volume, “N” Tube Set One male luer with cap, two female luers with caps, and a needle-free injection port 24
CS2000NS CryoStore 2000 EVA Freezing Bag, 180 – 450ml freezing volume, “N” Tube Set double aseptically packed One male luer with cap, two female luers with caps, and a needle-free injection port 12

Special Order

Best viewed on a desktop or laptop computer.

Will freezing bags break or fracture when impacted, dropped, etc. while frozen?

All plastics have a glass transition temperature unique to the identity and grade of polymer that makes up the plastic (it varies but is  -65C to -150C for our materials). Above this temperature, the bags are flexible. However, once the bag is cooled below its glass transition temperature, the films lose their plasticity. Any impact, pinch, cut, etc. can result in a clean fracture that radiates from the point of impact, akin to broken glass. Please see our white paper on How to Prevent Freezing Bag Breaks for more information.

What are the dimensions of a particular CryoStore Bag?

All sizing information can be found on the product brochure.

What is the expiration date of CryoStore Products?

CryoStore Bags and Accessory Sets: 4 years

I have a problem with a product, what is the complaint procedure?

Please report it as soon as possible. Contact the OriGen head office or your sales representative. Please retain the product and its packaging, as this will help us in our investigation and findings. All complaints will receive a written or oral response acknowledging receipt of the product and initial findings.

Where can I find the Instructions for Use (IFU) or Certificate of Conformance (CoC) for the product I received?

An IFU and CoC will be in your original shipment box. If these items are misplaced, you can access the IFU and CoC for your OriGen products through the Client Login. If you do not have a current login, you will need to register for an account through that page.

Damodharan SN, Walker KL, Forsberg MH, et al. Analysis of ex vivo expanded and activated clinical grade human NK cells after cryopreservation. Cytotherapy, 22(8):450-457, 11 Jun 2020. PMID: 32536506

Kilbride P, Meneghel J, Creasey G, et al. Automated dry thawing of cryopreserved haematopoietic cells is not adversely influenced by cryostorage time, patient age or gender. PLoS One, 15(10):e0240310, 26 Oct 2020. PMID: 33104704

Setia RD, Arora S, Handoo A, et al. Outcome of 51 autologous peripheral blood stem cell transplants after uncontrolled-rate freezing (“dump freezing”) using -80°C mechanical freezer. Asian J Transfus Sci, 12(2):117-122, 01 Jul 2018. PMID: 30692795.

F Aerts-Kaya, G Koca, P Sharafi, , et al. Automated washing of long-term cryopreserved peripheral blood stem cells promotes cell viability and preserves CD34+ cell numbers. Bone Marrow Transplantation. Volume 53, pages 1225–1227 (2018).

Huang J, Khan A, Au BC, Barber DL, et al. Lentivector Iterations and Pre-Clinical Scale-Up/Toxicity Testing: Targeting Mobilized CD34+ Cells for Correction of Fabry Disease. Mol Ther Methods Clin Dev, 5:241-258, 12 May 2017. PMID: 28603745

Morello, W., Budelli, S., Bernstein, D. A., Montemurro, T., Montelatici, E., Lavazza, C., … & Montini, G. (2022). First clinical application of cord blood mesenchymal stromal cells in children with multi-drug resistant nephrotic syndrome. Stem Cell Research & Therapy, 13(1), 1-9.

Special order items will always be manufactured to order – plan for minimum quantities and extended lead times.
